All-In-One Abrasive Machining Center

  • Positioning Accuracy Down to .001" or 25 Micron
  • Integrated Water Recirculation System
  • Integrated Abrasive Hopper (Dual Optional)
  • 230v Single Phase Operation
  • No water Supply Needed
  • No Drain Needed
  • True 3 Axis Control
  • Table Vibration Isolaters
  • Pump and Motor Vibration Isolators
  • Optional Dual Media Mixing
  • Optional Machine Vision System

The Hydren Systems HSB24 Abrasive Machining Center is the ideal solution when an ultra compact self sustaining solution is needed. With a built in 3 stage filtered recirculation system, the HSB24 does not require a water supply or drain to operate. Utilizing the most innovative design solutions in the industry, vibration isolation, and a fully contained design. The HSB24 has a state of the art rigid stainless steel frame, tank, and paneling that speaks to our commitment to quality and reliability. Our HSB24  is well suited for materials ranging from stainless  to carbon fiber composites.




  •  A  X-Y cutting envelope of 24" x 24"
  • Electronic Abrasive Metering Control
  • Fully Enclosed
  • Stainless Steel Tank
  • Full Seam Welded Stainless Frame
  • Fabricated and Manufactured in U.S.A.
  • Easy to use Windows Based Touch Screen Control
  • Integrated Pump and Motor
  • Mobile Design With Locking Casters
  • 3 Stage 5 micron Filtration System
  • Makrolon Polycarbonate Panels
WATER-ONLY

Applications

COMPOSITES
GLASS

Hydren Systems LLC.

11900 N LA CANADA DR #70027

Oro Valley, AZ. 85737 us



1-(520)-777-5166

Info@HydrenSystems.com

STAINLESS

ADDRESS

CERAMICS

OVERVIEW

HYDREN SYSTEMS HSB24

SPECIFICATIONS
